China Lipo Battery Manufacturer Custom-made Rechargeable Curved Battery BZ 252240 100mAh 3.7V Flexible Battery
Price: US $3.5-4.2 / Piece
Min. Order: 5,000 Pieces
Please contact us for the order !
- Place of Origin: Guangdong, China
Brand Name: BZ
Model Number: 252240
Type: Li-polymer
Nominal Voltage: 3.7V
Size: 2.5*22*40mm
Nominal Capacity: 100mAh
Product name: 252240 Li-ion battery
Warranty: 1 Year
Weight: 1.8g
Cycle life: 500 Times
Capacity: 100mah
Voltage: 3.7V
Application: Small Battery for Wearable Device
Certificate: CE/RoHS/UN38.3/MSDS
Payment: Paypal.TT.Escrow.Western Union
Max charge current: 1C
Product Parameters
|
No. |
Item |
General Parameter |
Remark |
|
|
1 |
Rated Capacity |
Typical |
110mAh |
Standard discharge（0.2C C5A) after Standard charge |
|
Minimum |
100mAh |
|||
|
2 |
Nominal Voltage |
3.7V |
Mean Operation Voltage |
|
|
3 |
Voltage at end ofDischarge |
2.75V |
Discharge Cut-off Voltage |
|
|
4 |
Charging Voltage |
4.2±0.03V |
|
|
|
5 |
Internal Impedance |
≤300mΩ |
Internal resistance measured at AC 1KHZ after 50% charge The measure must uses the new batteries that within one week after shipment and cycles no more than 5 times |
|
|
6 |
Standard charge |
Constant Current 0.2C5AConstant Voltage 4.2V0.01 C5A cut-off |
Charge time : Approx 6h |
|
|
7 |
Standard discharge |
Constant current 0.2 C5Aend voltage 2.75V |
|
|
|
8 |
Fast charge |
Constant Current 0.5C5AConstant Voltage 4.2V0.01 C5A cut-off |
Charge time : Approx 3.5h |
|
